VComm Set Radio/ICS Name

ID:  2059

Object Description

The VComm Set Radio/ICS Name object can be used in conjunction with VComm Radio Objects to create a name to be tagged onto the existing HLA RTI Object Identifier Name. This object only works with radios engaged in an HLA exercise. Using this object with a DIS radio has no effect.

To use the object, simply connect the output handle of a radio/intercom object to the radio handle input of this object. The data collected on the input pin is sent to the radio/intercom object and can be changed while V+ is running.

Input Pins

HNDL

Radio handle from either the VComm GENERIC Radio, V8 DIS Only, VComm GENERIC Radio, V8 DIS/HLA, or VComm Simple Intercom (DIS/HLA) objects.

ENABLE

The ENABLE pin enables the object to provide the connection to the adjacent device channel. A value of 0 disables it. Any non-zero value enables it.

Static Data

Name

This is a string which represents the name tag to be catenated to the HLA RTI Object Identifier Name.

To set the Name string:

Example

The figure below presents an example of how the VComm Set Radio/ICS Name object is used. In this example, the radio's name tag is set to Comm 1.
